Mechanical Keyboard and where to find them
This list will help you quickly find your favorite layout and you can start DIY your own custom keyboard.
Quick links
Keyboard:
Components:
Links:
Normal Keyboards
Name
Size
Description
136%, 147 key
A 147-key 3d printed keyboard, along with custom profile keycaps.
100%, Full size
GH80-3000 is intended to be a replacement PCB of the Cherry Corp.
100%, Full size
Fullsize Custom PCB Filco Compatible.
97%, Full size
A compact fullsize keyboard.
87%, TKL
HacKeyboard is a mechanical keyboard built from scratch using SMK Alps Mount switches from an old Monterey K108 keyboard and Alps compatible keycaps from an old NGS keyboard. It has several features that are not usually found in commercial keyboards: internal keylogger, macro recording, internal USB Hub 2.0, internal flash drive, customizable LED colors, customizable LED effects;
87%, TKL
The XMMX is a Tenkeyless PCB designed to work with MX compatible switches as well as ALPS SKCL/SKCM and their clones. This PCB is inteded to fit the Cooler Master Quickfire Rapid (not the Rapid-i) and the Filco Majestouch 2 TKL cases, although it could fit some other commercial TKL cases.
87%, TKL
TKL keyboard that can be entirely assembled using only through hole components, including usb type c.
87%, TKL
A Tenkeyless PCB inspired by Phantom, for customizing Filco Majestouch 2.
70%
70% with space between F-row and number row.
70%
Toad with support for MX and Alps switch.
68%
68%
68%
3D printed keyboard.
65%
65% keyboard assembled with only through hole components, including usb type-c.
65%
An open source O-ring gasket mount keyboard.
63%
63-key keyboard supports slide potentiometer, rotary encoder and oled screen.
60%
A simple MX/Alps 60% board that just works.
60%
Split 60% keyboard with trackpoint.
60%
The most popular 60% keyboard pcb.
60%
60%
This universal 60% PCB is designed to support as little layouts as possible without limiting usability for most users.
60%
Poker X compatible 60% size PCB supports various Alps switch keyboard layouts like AEK, Omnikey, Dell, V60MTS and Infinity.
60%
60% keyboard using STM32.
60%
60% BLE keyboard using nRF51822 as the main controller, CH554 as the USB chip.
60%
An open source O-ring gasket mount keyboard.
56%
56-key mechanical keyboard for Oyayubi-shift Japanese input.
59%
A reduced size keyboard, but not quite 60%.
50%
48%
47.2%
43%
40%
40%
WKL compact 40% keyboard PCB.
40%
MiniVan-compatible PCB based on an STM32MCU.
40%
RGB underglow 40% keyboard.
40%
It’s a 40%, with an easy to use layout that works well for typists, but perhaps not designers or programmers. Can be 3d printed.
40%
Tanuki is a 40% keyboard that uses a split spacebar design to comfortably switch between layers.
40%
30%
27%
The pain27 is an open source keyboard project to make an easily usable, yet completely and utterly unusable qwerty keyboard with all the letters of the english alphabet, a spacebar, and nothing else.
<30%
A 28-key semi-ortholinear mechanical keyboard.
Symmetrical SemiErgo layout keyboard.
87%, TKL
[THIS HAVE NOT BEEN TESTED YET]
TKL keyboard with RGB on each button.
68%
[THIS HAVE NOT BEEN TESTED YET]
The Split 65% Keyboard.
60%
[THIS HAVE NOT BEEN TESTED YET]
Bluetooth 60% keyboard.
Ergonomics Keyboards
Name
Description
Arisu
The layout is inspired by Lyn’s EM7 and TGR Alice with some modification.
Case
PCB
An 3D printable Alice-like mechanical keyboard.
An 3D printable Alice-like JIS-layout TKL mechanical keyboard.
BMEK is an ergonomic keyboard in the spirit of Lyn’s EM7 and TGR Alice. Notable differences are the more HHKB-like layout and the and the more symmetric looks due to the space bars and left key cluster arrangement.
Alice like ergo keyboard using only THT parts
The Atreus is a mechanical keyboard designed primarily to match the shape of human hands and to be as portable as possible. The case measures 26x12cm and lacks even a number row, relying heavily upon the fn key.
This version utilizes a Pro Micro for its controller and has a 62 key layout.
Unsplitting the Iris keyboard.
A 60% (12x5) split keyboard with staggerd column layout.
DIY 60% Split Keyboard.
60% split keyboard.
Ergodox is a keyboard project designed with ergonomics in mind, it uses 76-80 Cherry MX style mechanical switches laid out in a columnar stagger (rather than the more conventional row stagger) layout with components that can easily be sourced. The keyboard is completely programmable and can be flashed with several different firmware options.
Lily58 is 6×4+4keys column-staggered split keyboard.
Infinity ErgoDox
Left handed: https://github.com/kiibohd/pcb/tree/master/ICED%20-%20Left
Right handed: https://github.com/kiibohd/pcb/tree/master/ICED%20-%20Right
Sofle is 6×4+5 keys column-staggered split keyboard with encoder support.
A split ergo 4x6 keyboard with 2 or 3 thumb keys and extra inner macro keys.
The Redox project is an open-source, ergonomic split mechanical keyboard. This repository will be used to share information about the project and instruction on how to use and assembly the Redox keyboard.
The Dactyl is a parameterized, split-hand, concave, columnar, ergonomic keyboard.
The main change is that the thumb cluster was adapted from the ManuForm keyboard (geekhack). The walls were changed to just drop to the floor.
Wireless Split Ergonomic Keyboard.
A mitosis clone with more keys!!
Split wireless QMK powered keyboards
Corne keyboard, a split keyboard with 3x6 column staggered keys and 3 thumb keys, rgb, based on Helix.
MiniDox
A split ergonomic keyboard pcb with usb type c.
An ergonomic keyboard heavily inspired by the Atreus, Iris and Atreis keyboards.
Ortholinear Keyboards
Name
Description
A thumb-chorded 47-key keyboard
https://github.com/olkb/planck_thk
The 4x12 ortholinear keyboard kit made by through hole components only.
The PCB fits in the Planck formed bottom, and in theory it should fit into the Planck milled bottom
An alps-only blocked 4x12 (44 key) ortho with piezo support.
Extremely low cost ortholinear keyboard.
DIY low-profile ortholinear, with custom PCB, Kailh Choc Browns, and vintage Plum keycaps.
3x10 keyboard.
4x12 keyboard using pro micro and kailh choc.
7x4 ortho linear split keyboard.
A compact split ortholinear keyboard with screen.
Let’s Split
Split ortholinear keyboard with rgb underglow.
PCB
Case
40%
40%
The goal of this project is to build a Let’s Split keyboard clone with a number of alternative features.
6×4 +1keys Split Keyboard.
For Science is a 46 key ortholinear split keyboard PCB with a 3 key thumb cluster.
Zen Keyboard
Numpad/Macropad
Name
Description
This is a custom numeric pad that is designed to be usable on the right side of the keyboard or on the left (With a mirrored layout if required). There is a gap in the top row and the second row of 1.25U. The top row can be broken off by simply scoring the two brifges and snapping. The bottom 5 rows can then be used in conjunction with a 60%/65% keyboard.
Hot-swappable, RGB-backlighted, OLED featured, mechanical numpad.
17-key numpad assembled with only through hole components, including usb type-c.
A single-PCB numpad kit.
It’s a separate 10 key with some extra keys to allow it to stand alone for number crunching or gaming.
Simple 4x4 numpad with a rotary encoder.
It’s a separate 10 key with some extra keys to allow it to stand alone for number crunching or gaming.
Macropad that’s look like game boy cart, can be 3d printed.
Fusion 360 file
A 4x4 custom numpad.
kbord is a programmable keypad with 15 mechanical keys, each of which can be set to execute a script when pressed.
5x4 numpad.
An Open-source 5-key Keypad.
3x3 Macropad PCB.
4-Key Osu Keypad.
A tiny, fully featured 4-key macropad PCB.
A six keys macro pad made by Cookpad.
A small board with space for 4 ISO enter keys with PCB mount Cherry stabilizers. Powered by a Pro Micro.
1x4 keypad with led.
Others Keyboards
Name
Description
An ergonomic, compact, mechanical keyboard
Some other collection of mechkey kicad pcb
Make handwiring keyboard easier.
For customize keyboard connector and pcb.
Controller
Name
Description
ATXmega controller that have awesome support for wireless, can use with Logitech receiver, with usb type c. Support keyplus firmware.
Arduino pro micro clone with usb type c. Support TMK, QMK.
It is a breakout board of BL654 (nrf 52840 module) which is conscious of compatibility with Pro Micro, and it can correspond to both USB / Bluetooth Low Energy. Support BlueMicro, QMK firmware.
Arduino Pro Micro-sized breakout board for E73-2G4M08S1C (nRF52840) modules.
Adafruit Feather 32u4 Bluefruit LE
Support QMK with bluetooth out of the box.
Adafruit Feather Bluefruit nRF52
Support BlueMicro firmware.
With this you can change keymap and use functions TMK firmware offers on your USB keyboard.
Convert old keyboard socket to usb.
Case
Name
Size
Description
87%, TKL
Compatibility: Phantom, Universal TKL Plate, Filco TKL, Winkeyless, Gon
87%, TKL
Compatibility: Phantom, Universal TKL Plate, QFR, Filco TKL
87%, TKL
Compatibility: Unknown
87%, TKL
Compatibility: XD87 PCB
40%
3D printed 40% case inspired by GameBoy.
60%
Compatibility: GH60, Poker, Poker 2, Pure, Pure Pro
60%
Compatibility: Standard 60% case, hhkb
68%
Compatibility: Whitefox
68%
Compatibility: TGR Alice and compatible pcb
68%
Compatibility: TGR Alice and compatible pcb
68%
Compatibility: Arisu
Compatibility: Infinity ergodo
3d printed case for Redox keyboard.
Plate
Name
Size
Description
60%
Compatibility: Infinity, HHKB, Tai-Hao, …
~
Collection of various plates …
Keycaps
- SA profile 1 - 3D model of SA profile keycaps.
- SA profile 2 - Another 3D model of SA profile keycaps.
- Cherry profile 1 - 3D model of Cherry profile keycaps.
- Cherry profile 2 - Another 3D model of Cherry profile keycaps.
- DSA profile - 3D model of DSA keycaps.
- XDA profile - 3D model of XDA keycaps.
- Kailh low profile - 3D model of kailh low profile keycaps.
Firmware
- EasyAVR - EasyAVR is a keyboard firmware and keymapper GUI for custom keyboards based on USB AVRs. It is powerful but also really easy to use.
- TMK - A very popular firmware that support Atmega32u4 powered keyboard.
- QMK - Base on TMK but support a lot of controller, support RGB, easy to use.
- The VIA - QMK based firmware for the view app.
- Keyplus - An easy to use, wired and wireless modular keyboard firmware, for both ATXmega family and atmega32u4.
- BlueMicro - A Keyboard Firmware for nRF52832 Boards with a pinout compatible with the Arduino Pro Micro.
- MK32 - BLE keyboard firmware for ESP32 microcontrollers,designed to be relativley easily customizable.
- Bluetosis - Bluetooth firmware for the Mitosis keyboard.
- Kaleidoscope - Flexible firmware for Arduino-powered keyboards.
- Anne Key - Firmware for Anne Pro Keyboard written in Rust.
- Lotlab/nrf52-keyboard - TMK based keyboard firmware for nRF52 series, now support both nRF52810 and nRF52832.
- Lotlab/nrf51822-keyboard - This is a firmware based on nrf51822 Bluetooth keyboard, which uses nRF SDK 10.0 as the underlying hardware driver, and uses TMK keyboard library as the upper part of the keyboard function.
- Keyberon - Keyboard firmware written in Rust.
- Key To Key - Rust libary for building keyboard firmwares.
- Polymer firmware - Polymer keyboard firmware.
- Pipit keyboard - Firmware and config tools for chording keyboards.
- rusty-c - QMK in rust.
Tutorials
- PCB Designer Guide by ai03
- Keyboard PCB Guide by ruiqimao
- A modern handwiring guide
- Hand wiring a let’s split (pro micro)
- How to integrate a trackpoint in a mechanical keyboard (TMK, Teensy)
- lets-split-guide - This guide covers building a Let’s Split v2.
- the 1-Key-Keyboard project - One key keyboard using Attiny85.
- 4-key-keyboard - Four key keyboard using Attiny85.
Tools
- Keyboard Layout Editor: This is a web application that enables the editing of keyboard-layouts, i.e., the position and appearance of each physical key.
- Keyboard Layout 3D Viewer: Render 3D keyboard from KLE json.
- Keycap Renders: Render 3D keycap set.
- Plate & Case Builder: keyboard top plate CAD files generator, for keyboard-layout-editor generated layouts.
- ai03 Plate Generator: An advanced plate generator which doesn’t result in 13.99999mm cutouts. Also fillets the cutouts so you don’t have to waste hours later
- ai03 Plate Generator - An advanced plate generator which doesn’t result in 13.99999mm cutouts.
- Keyboard Layouter Plugin - Keyboard Layouter is a plugin for KiCad(pcbnew). This plugin places switch footprints in the location specified by JSON of Keyboard Layout Editor.
- mrkeebs Pcb Generator - Quickly create PCB from KLE json.
- Kalerator - pcb generator for keyboard-layout-editor generated layouts.
- Keyboard Firmware Builder - online QMK Firmware Builder. (2+ years behind QMK firmware master).
- QMK Configurator - an open source configurator for QMK Firmware.
- TMK Firmware Builder - online TMK Firmware Builder.
- Parametric Mechanical Keycap Library - is a keycap and keyset construction library for mechanical keyboards, written in openSCAD.
- KiCad Parts by Ai03 - KiCad Library of custom MX-Alps footprints
- KiCad Parts by Daprice - KiCAD footprint library for kailh choc and MX-style mechanical switches
- KiCad Parts by Keebio - Various KiCAD footprints for mechanical keyboard parts
- KiCAD Parts by TMK - KiCad modules for keyboard design
- Keyswitch Datasheets
- QMK Proton C symbol/footprint for KiCad, Eagle
- ESP32-kiCAD-Footprints
- *
Contributing
Contributions welcome!
