1、实现转盘数据动态配置（可通过接口获取）

2、背景色通过分隔配置

3、转动速度慢慢减速，最后停留在每一项的中间，下一次开始从本次开始

4、当动画停止后在对应事件中自定义生成中奖提示。

5、本次中奖概率随机生成，也可自定义配置

实现代码

html

复制代码

``<template>
<div class="graph-page">
<div class="plate-wrapper" :style="${bgColor};">
<div class="item-plate" :style="plateCss(index)" v-for="(item, index) in plateList" :key="index" >
<img :src="item.pic" alt="">
<p>{{item.name}}</p>
</div>
</div>
<div @click="handleClick" class="btn"></div>
</div>
</template>``

css

复制代码

`<style lang="less" scoped>
.graph-page {
width: 540px;
height: 540px;
margin: 100px auto;
position: relative;
}
.plate-wrapper {
width: 100%;
height: 100%;
border-radius: 50%;
border: 10px solid #98d3fc;
overflow: hidden;
}
.item-plate {
position: absolute;
left: 0;
right: 0;
top: -10px;
margin: auto;
}
.item-plate img {
width: 30%;
height: 20%;
margin: 40px auto 10px;
display: block;
}
.item-plate p {
color: #fff;
font-size: 12px;
text-align: center;
line-height: 20px;
}
.btn {
width: 160px;
height: 160px;
background: url('https://www.jq22.com/demo/jquerylocal201912122316/img/btn_lottery.png') no-repeat center / 100% 100%;
position: absolute;
left: 0;
right: 0;
top: 0;
bottom: 0;
margin: auto;
cursor: pointer;
}
.btn::before {
content: "";
width: 41px;
height: 39px;
background: url('https://www.jq22.com/demo/jquerylocal201912122316/img/icon_point.png') no-repeat center / 100% 100%;
position: absolute;
left: 0;
right: 0;
top: -33px;
margin: auto;
}
</style>`

其中背景色采用间隔配置，扇形背景采用锥形渐变函数conic-gradient可实现。

每个转项的宽度和高度可参照以下图片，所有奖品的div都定位在圆心以上，根据圆心转动，所以旋转点为底部中心，即：transform-origin: 50% 100%;

可采用监听transitionend事件判断动画是否结束，可自定义中奖提示。


复制代码

``<script>
export default {
data() {
return {
plateList: [],
isRunning: false, //判断是否正在转动
rotateAngle: 0, //转盘每项角度
baseRunAngle: 360 * 5, //总共转动角度,至少5圈
totalRunAngle: 0, //要旋转的总角度
activeIndex: 0, //中奖index
wrapDom: null //转盘dom
}
},
computed: {
bgColor(){ //转盘的每项背景
let len = this.plateList.length
let color = ['#5352b3', '#363589']
let colorVal = ''
this.plateList && this.plateList.forEach((item, index)=>{
colorVal += ${color[index % 2]} ${(360/len)*index}deg ${(360/len)*(index+1)}deg,
})
return background: conic-gradient(${colorVal.slice(0, -1)})
},
plateCss(){ //转盘的每项样式
if(this.plateList && this.plateList.length){
return (i) => {
return `
width: ${Math.floor(2 270 Math.sin(this.rotateAngle / 2 * Math.PI / 180))}px;
height: 270px;
transform: rotate(${this.rotateAngle * i + this.rotateAngle / 2}deg);
transform-origin: 50% 100%;
`
}
}
return ()=>{''}
},
},
created(){
this.plateList= [
{ name: '手机', pic: 'https://bkimg.cdn.bcebos.com/pic/3801213fb80e7bec54e7d237ad7eae389b504ec23d9e' },
{ name: '手表', pic: 'https://img1.baidu.com/it/u=2631716577,1296460670&fm=253&fmt=auto&app=120&f=JPEG' },
{ name: '苹果', pic: 'https://img2.baidu.com/it/u=2611478896,137965957&fm=253&fmt=auto&app=138&f=JPEG' },
{ name: '棒棒糖', pic: 'https://img2.baidu.com/it/u=576980037,1655121105&fm=253&fmt=auto&app=138&f=PNG' },
{ name: '娃娃', pic: 'https://img2.baidu.com/it/u=4075390137,3967712457&fm=253&fmt=auto&app=138&f=PNG' },
{ name: '木马', pic: 'https://img1.baidu.com/it/u=2434318933,2727681086&fm=253&fmt=auto&app=120&f=JPEG' },
{ name: '德芙', pic: 'https://img0.baidu.com/it/u=1378564582,2397555841&fm=253&fmt=auto&app=120&f=JPEG' },
{ name: '玫瑰', pic: 'https://img1.baidu.com/it/u=1125656938,422247900&fm=253&fmt=auto&app=120&f=JPEG' }
]
this.rotateAngle = 360 / this.plateList.length
this.totalRunAngle = this.baseRunAngle + 360 - this.activeIndex * this.rotateAngle - this.rotateAngle / 2
},
mounted(){
this.$nextTick(()=>{
this.wrapDom = document.getElementsByClassName('plate-wrapper')[0]
})
},
beforeDestroy(){
this.wrapDom.removeEventListener('transitionend', this.stopRun)
},
methods:{
handleClick(){
if(this.isRunning) return
this.isRunning = true
const ind = Math.floor(Math.random() * this.plateList.length)//通过随机数返回奖品编号
this.activeIndex = ind
this.startRun()
},
startRun(){
// 设置动画
this.wrapDom.setAttribute('style', `
${this.bgColor};
transform: rotate(${this.totalRunAngle}deg);
transition: all 4s ease;
`)
this.wrapDom.addEventListener('transitionend', this.stopRun) // 监听transition动画停止事件
},
stopRun(){
this.isRunning = false
this.wrapDom.setAttribute('style', `
${this.bgColor};
transform: rotate(${this.totalRunAngle - this.baseRunAngle}deg);
`)
}
}
}
</script>``
